Tp-Link VIGI NVR2008H-8MP VIGI 8 Channel PoE+ Network Video Recorder

Camera

• Image Sensor: 1/3.06” Progressive Scan CMOS
• Shutter Speed: 1/3 to 1/10000 s
• Slow Shutter: Yes
• Minimum Illumination: 0.005 Lux; 0 Lux with IR/White Light
• Day/Night Mechanism: IR Cut Filter
• Day/Night Switch: Unified/Scheduled/Auto

Lens

• Type: Fixed Focal Lens
• Focal Length: 4 mm
• Aperture: F1.6
• FOV: Horizontal 80°, Vertical 43°, Diagonal 94°
• Lens Mount: M12*0.5
• DORI Distance: Detect: 80 m, Observe: 33 m, Recognize: 16 m, Identify: 8 m

PTZ

• Pan/Tilt Range: Pan 0° to 348°, Tilt 0° to 120°
• Pan/Tilt Speed: Configurable from 8° to 44°/s, Preset Speed: 44°/s
• Manual Control Speed: Configurable from 8° to 35°/s
• Presets: 300
• Patrol Scan: 8 patrols, up to 8 presets for each patrol
• Power-off Memory: Yes, auto restore after power failure
• Park Action: Yes, Preset, Patrol Scan
• 3D Positioning: Yes
• Angle Adjustment (Manual): Pan 0° to 348°, Tilt 0° to 120°

Illuminator

• IR LED: 2 LEDs, Range: 30m, Wavelength: 850nm
• White LED: 2 LEDs, Range: 30m
• Illuminator On/Off Control: Auto/Scheduled/Always on/Always off

Video

• Max. Resolution: 2560 x 1440
• Main Stream:
  • Frame Rate (50Hz): 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
  • Frame Rate (60Hz): 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
  • Resolution: 2560x1440, 2304x1296, 2048x1280, 1920x1080, 1280x720
  • Note: Image rotation at 90° or 270° supports up to 20fps
• Sub-Stream:
  • Frame Rate (50Hz): 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
  • Frame Rate (60Hz): 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
  • Resolution: 640x480, 352x288, 320x240
  • Note: Image rotation at 90° or 270° supports up to 20fps
• Bit Rate Control: CBR, VBR
• Video Compression: Main Stream: H.265+/H.265/H.264+/H.264, Sub-Stream: H.265/H.264
• H.264 Type: Main Profile/High Profile
• H.264+: Main Stream Supported
• H.265 Type: Main Profile
• H.265+: Main Stream Supported
• Video Bit Rate: Main Stream: 256 Kbps to 3 Mbps, Sub-Stream: 64 Kbps to 512 Kbps


• Image Settings: Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance, Prevent Overexposure to Infrared Light, HLC Adjustable, Rotation (90°/270°)
• Image Enhancement: BLC/3D DNR/HLC/SmartIR
• Wide Dynamic Range: DWDR
• SNR: ≥ 52 dB
• Image Parameters Switch: Yes
• Privacy Mask: Up to 4 Masks
• ROI: 1 Region
• OSD Setting: Yes

Audio

• Audio Communication: Two-Way Audio
• Audio Input: Yes
• Audio Output: Yes
• Audio Compression: Yes
• Audio Sampling Rate: 8KHz
• Environment Noise Filtering: Yes
• Audio Bit Rate: 64 Kbps (G.711 alaw)

Network

• Protocol: TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS
• ONVIF: Yes
• API: ONVIF
• Simultaneous Live View: 2 Main Streams & 2 Sub-Streams
• Client: VIGI App, VIGI Security Manager, Web UI
• Web Browser Support: Google Chrome 57+, Firefox 52+, Safari 11+, Microsoft Edge 91+
• Cloud: Yes
• Security: Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication

4G

• Standard: LTE-TDD/LTE-FDD/WCDMA
• SIM Type: Nano SIM
• Category: 4
• Frequency Bands: LTE-FDD: B1/3/5/7/8/20/28, LTE-TDD: B38/40/41, WCDMA: B1/5/8

Alarm and Event Management

• Smart Event: Human & Vehicle Classification, Intrusion Detection, Line-Crossing Detection, Region Entering/Exiting Detection, Object Abandoned/Removal Detection, People Detection, Vehicle Detection
• Basic Event: Motion Detection, Video Tampering Detection, Exception (Illegal Login)
• Alarm Linkage: Memory Card Video Recording, Message Push, Audible Warning, White Light Flashing
• Output Notification: Message Push

Interfaces

• Network Interface: 1 RJ45 10/100M Self-Adaptive Ethernet Port
• Reset Button: Yes
• Power: DC Power Port
• On-board Storage: Built-In Memory Card Slot, Supports MicroSD Card up to 256 GB
• Built-in Nano-SIM Card Slot: Yes
• Built-in Microphone: Yes, records within a 15-ft radius
• Built-in Speaker: Yes

General

• Operating Temperature: -30–60 °C
• Storage Temperature: -40–60 °C
• Operating Humidity: 95% or Less (Non-Condensing)
• Storage Humidity: 95% or Less (Non-Condensing)
• Package Contents: VIGI Network Camera, Quick Start Guide, Waterproof Cable Attachments, Mounting Accessories, Power Adapter
• Material: Plastic
• Net Weight: 0.69 Kg
• Gross Weight: 1.16 Kg
• Power Supply: 12V DC/1A, 5.5mm Coaxial Power Plug
• Antenna: 2 Dipole Omni-Directional Antennas
• Protection: IP66
• Product Dimensions (L x W x H): 120 × 182 × 201 mm (excluding antennas)
• Certifications: CE, RCM, BSMI, RoHS, NCC
