Video and Audio
IP Video Input: 8-ch, up to 32 MP resolution
(After ultra HD resolution mode is enabled, supports up to 8-ch 32 MP/24 MP IP video inputs.)
Incoming Bandwidth: 128 Mbps
Outgoing Bandwidth: 256 Mbps
HDMI Output: 8K (7680 × 4320)/30Hz, 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz
VGA Output: 1920 × 1080/60Hz
Video Output Mode: HDMI/VGA independent output
CVBS Output: 1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480
Audio Output: 1-ch, RCA (Linear, 1 KΩ)
Two-Way Audio: 1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input)
Decoding
Decoding Format: H.265+/H.265/H.264+/H.264
Recording Resolution: 32 MP/24 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
(After ultra HD resolution mode is enabled, supports up to 8-ch 32 MP/24 MP IP video inputs.)
Synchronous Playback: 8-ch
Decoding Capability: 2-ch@32 MP (30 fps) + 2-ch@8MP (30 fps) / 10-ch@8 MP (30 fps) / 20-ch@4 MP (30 fps) / 40-ch@1080p (30 fps)
Dual-Stream Recording: Support
Stream Type: Video, Video & Audio
Audio Compression: G.711ulaw, G.711alaw, G.722, G.726, AAC, MP2L2
Network
Remote Connection: 128
Network Protocols: TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS, ONVIF (Version 2.2), OTAP
Network Interface: 2 × RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
Camera Access Protocol: ONVIF (Version 2.5), RTSP
Auxiliary Interface
SATA: 2 SATA interfaces
Capacity: Up to 16 TB capacity for each disk
Alarm In/Out: 4/1
USB Interface: Front panel: 1 × USB 2.0; Rear panel: 1 × USB 3.0
General
Power Supply: 12 VDC, 3.33 A
Power Consumption: ≤ 15 W (without HDD)
Working Temperature: -10 °C to 55 °C (14 °F to 131 °F)
Working Humidity: 10% to 90%
Dimensions (W × D × H): 385 × 315 × 52 mm (15.2" × 12.4" × 2.0")
Weight: ≤ 3 kg (without HDD, 2.2 lb.)
Certification
FCC: Part 15 Subpart B, ANSI C63.4-2014
CE: EN 55032:2015+A1:2020, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019, EN 50130-4:2011+A1:2014, EN 55035:2017+A11:2020
Obtained Certifications: CE, FCC, RoHS, REACH
